Finder 706184000000pas Sequence/Loss of Control Relay Phase Meter Modular 1Rt 208/480 Vac 6 A

Phase control and phase failure relays for three-phase networks Universal use esystems with UN 208 V to 480 V, 5060 Hze Detects phase failure error even in the presence of regenerated voltages Positive safety logic ethe output relay contact opens in the event of error detectione 2 versions: 1 switch, 6 A ewidth 17.5 mme, 35 mm rail mounting eEN 60715e European patent filed for the innovative principle underlying the 3-phase monitoring and error detection system.technical data sheet:Type of electrical connection Screw connectionWith pull-out terminals noRated control voltage Us 50Hz AC 170...520 VRated control voltage Us 60Hz AC 170...520 VType of voltage for AC drivePhase sequence detection yesPhase failure detection yesUndervoltage detection noOvervoltage detection noAsymmetry detection noMin. switch-on delay 0.5 s Min. deenergization delay 0.5 sNumber of NC contacts 0Number of contacts NO 0Number of exchange contacts 1 Width 17.5 mm Height 87 mm Depth 60.8 mm ''
