Schneider Electric Schneider Elec PBT – ITL 36 01 – Switch Charging ISW 3 Pole 100 A

Use of this switch/isolation & control. Opening and closing the function of an already circuit is protected against surintensités and open function. Number of Poles: 3 Category: AC-22 A Capacity to open: Yes Rated Current: 40 A 415 V AC 50/60Hz Assigned to use Voltage: 240 V AC 50/60Hz; 48 V DC Can be assigned, short circuit protection: 4.2 kA closing cuts only) Assigned short-lived maximum current: 1260 a Assigned isolation voltage: 500 V AC 50/60 Hz To wear Shock resistant Voltage: 6 kV Control Type: maneton How to installation: Fixed Mount: DIN rail mount Compatible with the bar's distribution block of the comb (up or down): Yes 9 mm pitch: 6 Height: 82 mm Width: 54 mm Depth: 75.5 mm Colour: White Indicator light: No Mechanical Life: 20000 cycle Electrical life: 15000 cycle Mode of connection: (top or bottom) terminals Type 50 mm² No End Of Flexible, 35 mm² Cable No End Of Tunnel and 35 mm² Flexible Cable with cable end Stripping wire length: 9 mm Maximum torque: 3.5 N.m Links to the documentation Manufacturer Schneider Electric Technical Specifications: interrupteur-sectionneur ISW 3P 40 A 415 V (a9s65340) Schneider Electric Technical Specifications: interrupteur-sectionneur ISW 3P 63 A 415 V (a9s65363) Schneider Electric Technical Specifications: interrupteur-sectionneur ISW 3P 100 A 415 V (a9s65391) Schneider Electric Technical Specifications: interrupteur-sectionneur ISW 3P 125 A 415 V (a9s65392)
