Testo 0628 7503 Temperature probe with aluminium sleeve (NTC)

Overview The temperature probe with aluminium sleeve and flat tip is suitable for measurements in liquids and pastes as well as for air temperature measurements. Thanks to its NTC sensor element, the probe provides precise temperature measurements with an accuracy of up to 0.2C. The temperature probe features a 2.4 m cable. For long-term measurements, you can mount the temperature probe permanently at the measuring location. To do this you only need a clamp or PG gland (not included in delivery). The temperature probe is waterproof in accordance with protection class IP65. Consequently, measurements can be taken outdoors for example. This probes response time t99 (time it takes for the probe to register 99% of the jump in temperature) of 190 seconds refers to measurements in moving water at +60C. This response time is extended when, for example, measurements are taken in still liquid, pastes or air. The perfect probe for any application Dont see the temperature probe you are looking for? Please contact us directly. We have a large range of standard temperature probes and we also manufacture customized probes specifically according to your personal requirements. For air temperature measurements, the response time is about 40 60 times higher than the indicated value measured in water. If you should require a rather sluggish temperature probe to measure air temperature, this probe is particularly suitable because it does not take brief temperature peaks into account at all, or only to a very small degree, when measuring temperature. For example, if you are planning to use this probe to measure air temperature in the refrigerator, briefly opening the refrigerator door would not take into account the temperature fluctuation which results from mixing the warm room temperature with the refrigerator temperature. If you need an air temperature probe with a fast response time, your best choice would be the exceptionally fast temperature probe 0602 0493 which has a large measuring range. Technical Data Temperature - NTC Measuring range: -30 to +90 °C Accuracy: ±0.2 °C (0 to +70 °C), ±0.5 °C (Remaining Range) Reaction time: 190 sec General Technical Data Protection class: IP65 Fixed cable: true Cable length: 2.4 m Diameter probe shaft: 6 mm. Length probe shaft: 40 mm
