Schneider Electric Merten Relais-Schalt-Einsatz 2fach MEG5162-0000

For resistive, inductive and capacitive loads such as incandescent lamps, energy-saving lamps, NV halogen lighting with conventional transformer, electronic transformers, fluorescent lamps. With claw and screw attachment. With screw terminals. Functions: Switching two outputs. The module defines the way in which the function of the insert is used. External control via two PlusLink inputs xx rated voltage: AC 220/230 V, 50/60 Hz. Rated current: max. 10AX, cos Phi 0.6 The total load of both channels must not exceed 14A. Outputs: 2 x N/O contacts. Max. Switching capacity per channel: Incandescent bulbs: 2200 W. HV halogen bulbs: 2000 W. NV halogen lamps with coiled transformer: 500 VA. Electronic transformers: 1050 W. Capacitive load: 10 A, 140 uF. Energy saving bulbs: 100VA Engine load: 1000VA Neutral conductor: required (3 conductor system) Connection cross section: max. 2 x 2.5 mm². To be completed with: button module Basic, single system M MEG5110-0300, System Design MEG5110-60xx button module Basic, 2-gang System M MEG5120-0300, System Design MEG5120-60xx. Button module comfort, 1-gang system M MEG5111-0300, system design MEG5111-60xx button module comfort, 2-way system M MEG5121-0300, system design MEG5121-60xx button module Comfort Plus with IR, 1-gang system M MEG5112-0300. Button module Comfort Plus, 2-gang system M MEG5122-0300. Wiser pushbutton module, 1-gang system M MEG5113-0300, system design MEG5113-60xx Wiser pushbutton module, 2-way system M MEG5123-03xx, system design MEG5123-60xx rotary control module system M MEG5252-03xx/-04xx. ARGUS 180 UP Sensor Module System M MEG5710-03xx/-04xx, System Design MEG5710-60xx ARGUS 180 UP Sensor Module with Switch System M MEG5711-03xx/-04xx, System Design MEG5711-60xx. ARGUS Presence 180/2.20 m UP Sensor Module System M MEG5530-03xx/-04xx ARGUS Presence Sensor Module with IR MEG5522-00xx Timer Module Standard System M MEG5754-03xx/-04xx. MEG5755-03xx/-04xx System Design MEG5755-60xx Timer Module Transmitter: extension plus, single system M MEG5119-0300, system design MEG5119-60xx extension plus, 2-way system M MEG5129-0300, system design MEG5129-60xx central station insert MEG5190-0000. Accessories: PlusLink 3 phase distributor MEG5130-0001. PlusLink extension MEG5130-000
