BEMATIK.COM BeMatik - Multlipicador selector and HDMI 2 input to 8 outputs

Multiplier, amplifier selector and 2 HDMI input ports and output ports 8. From Two HDMI Input Signals This device multiplies the selected signal into two identical outputs. This multiplier has the ability to store data (buffering), amplify and distribute for their output ports. HDMI also amplifies the signal to a cable length of 30 m. Specifications Selector HDMI ports. Has two female HDMI input ports of which one of them is selected as active port with a button on the front panel. HDMI port multiplier. The replica signal selected (or active signal) in the eight output HDMI female ports. The output ports are fully synchronized and replicating the same signal of the active input port. Signal Booster up to 30 m which varies according to the quality of the HDMI cable used and the environment. Supports a maximum of 15 m of cable at the entrance and 15 m of cable on the outputs. Possibility of cascading chain two or more multipliers to expand the system and obtain greater cable distances from the HDMI signal source (15 m additional). Supported resolution: 1920 x 1200 and 1080p. Compatible HDMI 1.3b, HDCP 1.0, HDCP 1.1 and HDCP 1.2. VGA Video formats supported: 640 x 480, 800 x 600, 1024 x 768 and 1920 x 1200. Video Formats DTV/HDTV supported: 480i, 576i, 480p, 576p, 720p, 1080i and 1080p. Working Frequency: Up to 225 MHz. Available switch (on and off) in the front panel and LED indicators on the front panel. Requires external power supply of 5 VDC (included). Compact size: 441 x 202 x 45 mm.
