Busch-Jaeger Switch Actuator Wave Line 6702

Busch Funkcontrol, up insert, Switch Actuator Wave Line, Switch Actuator Wave Line for switching electrical loads via radio. For Features: On/Off, timer switches and lighting scenes control system. For wall transmitter 6731 XXX, 6732 – XXX and 6733 – XXX for hand transmitter wave line 6780. For Windows sensor transmitter wave line 6. For universal sensor Wave Line Pink 6. Compatible with wave line media converter TP RF 6770. shut down delay: 10 sec. (5 minutes can be adjusted. Repeater function for booster range can be activated. For universal to or panel mounted. 3 wire connection technology (neutral wire required). Designed for installation in (D) flush-mounted sockets according to DIN 49073-1. Ansteuer bar for up to 32 transmitters addresses without hesitation. Receiving/Sending Frequency: 868 MHz. Coverage: Approximately 100 m (free field). Controls: adjustment potentiometer indication functions: Status Display of the output via light-emitting diode (LED). Rated voltage: + 10%/ – 10% Nominal frequency: 50 Hz Outputs: 1x opener or closer, potential-free Lastart Ohm with load: Rated current: 10 A. Ausgan
