H&R DRS-System Wheel spacer set 30mm per axle - Bolt pattern 4x108 - Hub 63,3mm - Bolt size M12x1,5 - compatible with Ford/Mazda

H&R TRAK+ wheels spacers provide a sporty look of your vehicle and can be used as well with serial - as also with special wheels. Via complex testing / road testing arranged with the TUV the technically possible wheels spacing for the concerned vehicle is identified. During construction-tries in the house of H&R the regulations for the components certificate or for the ABE are specified. With H&R TRAK+ wheels spacers the wheels can be put into the wheel housing exactly. H&R TRAK+ wheels spacers are available in various models as well as in various width from 6 up to 100mm per axis. All H&R TRAK+ wheels spacers are made in Germany! Technical data: Broadening per axis: 30mm (15mm per site) Bolt-hole: 4/108 Hub centring: 63,3mm Thread: M12x1,5 Attaching: nuts System: DRS The assembly of the DRS-system happens via the exchange of the standard knurled stud bolts against appropriately longer H&R-knurled stud bolts inside the wheel-flanges, respectively inside the brake drums. The longer H&R-knurled stud bolts are in scope of delivery. The attaching of the wheels happens with the existing nuts of the standard- or special wheels. TUV-report: Vehicle-specific TUV-reports, respectively reports about the Structural Durability of these wheels spacers you find on the H&R-homepage for free download if you type the H&R article-number: 30346331 In scope of delivery: 1 pair (2 pieces for one axis) incl. H&R kunrled stud bolts. Ford Cougar Typ BCV Ford Escort Typ ALD, ALF, ABT, ABFT, AWA Ford Escort Typ GAL, AAL, ABL, AFL, ALL, ANL Ford Fiesta Typ GFJ Ford Fiesta Typ JA8 Ford Fiesta Typ JAS, JBS Ford Fiesta Typ JH1, JD3 Ford Focus Ford Fusion Typ JU2 Ford KA Typ RBT Ford Mondeo Typ GBP, BFP, BAP, BNP Ford Puma Typ ECT Ford Scorpio Typ GGR, GFR, GNR Ford Sierra Typ BNG Hint(s): 11 Ford Sierra Typ GBG Hint(s): 11 Ford Street KA Typ RL2 Mazda 121 Typ JASM, JBSM Mazda 2 Typ DY
