fischer Fischer Pipe Clamp, Clamps, Pipe Clips FRS Plus 15 – 19 79441

The advantages / Product description The two-screw pipe clamp with rapid-locking mechanism Advantages The rapid-locking mechanism allows for fast and time-saving installation. The safety latch fastening guarantees pipe installation without the clamp springing open. The tight fit of the sound insulation insert prevents it from falling out when aligning the pipe. The combination connecting nut with M8/M10 thread enables optimised mounting choices. The two screws allow an easy adjustment to suit the outer pipe diameter. The screw's safety feature ensures trouble-free installation. The fischer pipe clamp FRS Plus is a two-screw pipe clamp made from zinc-plated steel in material quality DD11 with an M8/M10 combination connecting thread and a sound protection certificate. The plus rapid locking mechanism allows for quick and easy installation. The two-screw version enables optimised adjustment in line with the outer diameter of the pipe. Together with the combination connecting thread, this increases flexibility. This enables pipelines with an outer diameter of 12 to 119 mm to be securely fixed with a threaded rod or stud screw indoors. With a chlorine-free and silicone-free sound insulation insert, the pipe clamp meets the requirements of DIN 4109. Properties Material: steel DC01 (material no. 1.0330) acc. to DIN EN 10130 Zinc plating: electro zinc-plated, 5–9 µm Connecting nut: resistance welded, M8/M10, SW 13 Locking screw: flat head screw with combination recessed head Material sound insulation insert: EPDM; chlorine-free; silicone-free Sound insulation: for DIN 4109 Temperature range: -40 °C to +100 °C Hardness: 55 ± 5° Shore A Fire behaviour: DIN 4102: Class B2 The two-screw pipe clamp with rapid-locking mechanism Advantages The rapid-locking mechanism allows for fast and time-saving installation. The safety latch fastening guarantees pipe installation without the clamp springing open. The tight fit of the sound insulation insert prevents it from falling out when aligning the pipe. The combination connecting nut with M8/M10 thread enables optimised mounting choices. The two screws allow an easy adjustment to suit the outer pipe diameter. The screw's safety feature ensures trouble-free installation. The fischer pipe clamp FRS Plus is a two-screw pipe clamp made from zinc-plated steel in material quality DD11 with an M8/M10 combination connecting thread and a sound protection certificate. The plus rapid locking mechanism allows for quick and easy installation. The two-screw version enables optimised adjustment in line with the outer diameter of the pipe. Together with the combination connecting thread, this increases flexibility. This enables pipelines with an outer diameter of 12 to 119 mm to be securely fixed with a threaded rod or stud screw indoors. With a chlorine-free and silicone-free sound insulation insert, the pipe clamp meets the requirements of DIN 4109. Properties Material: steel DC01 (material no. 1.0330) acc. to DIN EN 10130 Zinc plating: electro zinc-plated, 5–9 µm Connecting nut: resistance welded, M8/M10, SW 13 Locking screw: flat head screw with combination recessed head Material sound insulation insert: EPDM; chlorine-free; silicone-free Sound insulation: for DIN 4109 Temperature range: -40 °C to +100 °C Hardness: 55 ± 5° Shore A Fire behaviour: DIN 4102: Class B2 Application and approval Applications For simple and easy fixing of pipes using threaded rods or stud screws Approvals FEB/FS-75/13 - 3 Applications For simple and easy fixing of pipes using threaded rods or stud screws Approvals FEB/FS-75/13 - 3 Applications For simple and easy fixing of pipes using threaded rods or stud screws Approvals FEB/FS-75/13 - 3 Assembly instruction Functionality Functionality
