Hager HAGADS966D FI/LS Switch, 16A 1P and NC, 0.03m

Residual current circuit breaker 1P+N 6kA C characteristic 16A 30mA Type A QC Residual current circuit breaker in accordance with DIN VDE 0664-20/EN61009-1 with QuickConnect terminal in accordance with DIN EN 60898-1, VDE 0641-11, at the outlet up to 20 A and at the access up to 63 A. Contact protection in accordance with IP2x DIN VDE 0106 part 100, blue test button and residual current indicator. Easy individual removal from the phase rail network. With VDE sign. Suitable for the subsequent installation of additional equipment. Can be labelled directly on the device. Rated current 16 A Release characteristic C Nominal cut-off capacity 6 kA Type of differential protection A Sensitivity 30 mA Number of poles 2 P Number of modules 2 Rated operating voltage Ue 230 V Make Hager or equivalent article ADS966D.
