Aristo Schneider AH7033, Drawing Board Geo, A3

The Aristo Geo Board drawing board for sheet format DIN A3 is the professional device among drawing boards and is considered the best basis for training as a technician. Aristo drawing boards impress with their simple and ergonomic operation, high stability and maximum precision when drawing. The L-shaped parallel drawing rail e is equipped with 2 scales, a yellow protractor and the proven 2-point guide. This allows smooth gliding and precise positioning. The stop-and-go mechanism with freewheel offers the possibility to fix the drawing rail while drawing. Two guide stops at the bottom of the guide groove prevent the drawing rail from accidentally slipping out. The lower measurement division on the drawing rail allows you to draw up to the edge of the sheet. The operation is carried out by means of an ergonomically shaped handle. A magnetic clamping rail with viewing window to control the sheet stop and an additional sheet clamp ensure the perfect fixing of the drawing paper. For complementary drawing with a compass, compass scaling allows you to quickly adjust radii. Non-slip nubs on the underside of the plate ensure a perfect grip on the work surface. The included transparent quick drawing triangle with hypotenuse 17 cm is equipped with a handle and underside ink nubs. It allows direct and indirect measurement of distances and angles as well as drawing horizontal and vertical lines and is also ideal for hatching. For storage and transport, the drawing board is packed in a robust cardboard case with carry handle.
