T.I.P. 31175 Garten Jet 750 Cast Iron Garden Pump, up to 2,800 l/h Flow Rate

T.I.P. Garten Jet 750 600 watt max. flow rate 2,800l/h Ideal starter model with robust cast iron pump housing and compact design. Self-aspirating pump and very smooth-running jet pump with on/off switch. Maintenance-free capacitor motor with thermal overload protection. Flexible use locations: Suitable for both mobile use and as a permanent installation. Diverse areas of application - e.g. watering or sprinkling gardens, filling and emptying basins or supply tanks, cleaning terraces and walking paths. Technical data: Motor: 600 watt Max. pressure head: 42 m Max. flow rate: 2,800 l/h Max. pressure: 4.2 bar Max. suction lift: 9 m Pump housing: Cast iron Max. fluid temp.: 35 °C Suction connection: 30.93 mm inside thread (1') Pressure connection: 30.93 mm inside thread (1') Connection cable: 1.5 m Packaging dimensions (cm): 27 x 37 x 19 Weight (total): 9.2 kg Article number: 31175 Pressure head and flow rate: 40 m - 2.5 l/min - 1.02 m³/h 30 m - 10 l/min - 0.60 m³/h 20 m - 25 l/min - 1.50 m³/h 10 m - 40 l/min - 2.40 m³/h The flow rate of a pump mainly depends on the pressure head. The term 'pressure head' refers to the height difference between the water surface and the water outlet. For example, if a pump sucks water from a depth of 5 metres and raises it to a height of 15 metres, the pressure head is 20 metres. The table above indicates the performance limits of the Garten Jet 750 pump at different pressure heads. At a pressure head of 20 metres, for example, a flow rate of 25 litres per minute or 1.5 cubic metres per hour can be expected for this pump.
