Springer 5G and E-Band Communication Circuits in Deep-Scaled CMOS (Analog Circuits and Signal Processing)

This book discusses design techniques, layout details and measurements of several key analog building blocks that currently limit the performance of 5G and E-Band transceivers implemented in deep-scaled CMOS. The authors present recent developments in low-noise quadrature VCOs and tunable inductor-less frequency dividers. Moreover, the design of low-loss broadband transformer-based filters that realize inter-stage matching, power division/combining and impedance transformation is discussed in great detail. The design and measurements of a low-noise amplifier, a downconverter and a highly-linear power amplifier that leverage the proposed techniques are shown. All the prototypes were realized in advanced nanometer scaled CMOS technologies without RF thick to metal option. From the Back Cover This book discusses design techniques, layout details and measurements of several key analog building blocks that currently limit the performance of 5G and E-Band transceivers implemented in deep-scaled CMOS. The authors present recent developments in low-noise quadrature VCOs and tunable inductor-less frequency dividers. Moreover, the design of low-loss broadband transformer-based filters that realize inter-stage matching, power division/combining and impedance transformation is discussed in great detail. The design and measurements of a low-noise amplifier, a downconverter and a highly-linear power amplifier that leverage the proposed techniques are shown. All the prototypes were realized in advanced nanometer scaled CMOS technologies without RF thick to metal option. Discusses the major implication of CMOS technology scaling on mm-Wave low power circuit design; Includes detailed design techniques, layout implementations and design examples of state-of-the-art  mm-Wave broadband quadrature oscillators, frequency dividers, low-noise amplifiers, downconverters, and highly-linear power amplifiers; Provide a reference work for neophytes as well as more experienced mm-Wave design engineers. About the Author Marco Vigilante (S’14–M’17) was born in Carpi, Italy, in 1988. He received the B.S. and M.S. degrees in electrical engineering from Università di Modena, Modena, Italy, in 2010 and 2012, and the Ph.D. degree from the University of Leuven (KU Leuven), Leuven, Belgium, in 2017. He is currently working as a research assistant at the MICAS laboratories of the KU Leuven in the field of high performance analog building blocks for mm-Wave transceivers designed in deep-scaled CMOS. Mr. Vigilante was the recipient of the IEEE Solid-State Circuits Society Predoctoral Achievement Award for 2016-2017 and the 2017 IEEE RFIC Symposium Best Student Paper Award–3rd Place. Patrick Reynaert was born in Wilrijk, Belgium, in 1976. He received the Master of Industrial Sciences in Electronics (ing.) from the Karel de Grote Hogeschool, Antwerpen, Belgium in 1998 and both the Master of Electrical Engineering (ir.) and the Ph.D. in Engineering Science (dr.) from the Katholieke Universiteit Leuven (K.U.Leuven), Belgium in 2001 and 2006 respectively. From 2001 to 2006, he was a Teaching and Research Assistant within the MICAS research group of the Department of Electrical Engineering (ESAT), K.U.Leuven, Belgium. While working towards his Ph.D. degree, his main research focus was on CMOS RF power amplifiers and analog circuit design for mobile and wireless communications. From 2001 to 2006, he was also a Lector at ACE-Group T Leuven, Belgium where he taught several undergraduate courses on electronic circuit design. During 2006-2007, he was a post-doctoral researcher at the Department of Electrical Engineering and Computer Sciences of the University of California at Berkeley. At the Berkeley Wireless Research Center, he was working on mm-wave CMOS integrated circuits within the group of Prof. Ali Niknejad. For this research, he received a Francqui Foundation fellowship from the Belgian American Educational Foundat
