Ascent, Center for Technical Knowledge Creo Parametric 3.0: Sheet Metal Design

The Creo Parametric 3.0: Sheet Metal Design learning guide enables you to use your introductory modeling skills to create sheet metal models, including wall, bends, notches, and form features. On completion of this course, you will have acquired the skills to confidently manipulate sheet metal geometry, adjust bend developed lengths, and convert solid parts. Topics Covered The sheet metal environment Primary and secondary walls Bend relief Corner relief Regular unbends, back bends, and cuts Notches and punches Bend features Unbending complex geometry Sheet metal forms Documenting a sheet metal part Converting solid parts Sheet metal setup Investigating a sheet metal part Prerequisites Creo Parametric: Introduction to Solid Modeling or equivalent Creo Parametric 3.0 experience.Please note that this learning guide uses commercial practice files which may not be compatible with the Student Edition of Creo Parametric
