CRC Press Integrated Product Design and Manufacturing Using Geometric Dimensioning and Tolerancing: 60 (Manufacturing, Engineering and Materials Processing)

This book addresses the preparation and application of design layout analyses with concurrent engineering teams in six steps that capture design intent and add value to design process. It offers tools for eliminating costly trial-and-error approaches and deliver economically viable products. The authors discuss product design techniques that alleviate the constraints between product definition, manufacturing, and inspection, the prediction of variation effects on product function and manufacturing efficiency, functional inspection techniques that include CMM measurement, optical comparators, and surface plate and functional gaging, and more.
